TECOTEC completely delivery AMADA machine multiprocess center MX-150 for HCMC UNIVERSITY OF TECHNOLOGY

From December 21st, 2016 to December 27th, 2016 TECOTEC engineer combined with AMADA expert to install and handover The Multiprocess Center MX-150 which is belongs to “Laboratory of Design Technology and Advanced Processing – HCMC University of Technology - HCMC National University”.

The Multiprocess Center MX-150 is produced by AMADA – Japan.

Features:

  • Five-axis of motion can be performed with a higher level of accuracy thanks to a pivot independent structure that prevents incremental positioning errors from the pivot point.
  • Very high machining accuracy is achieved by a design concept equivalent to that of a grinding machine..Positioning accuracy: Linear axis ±1 μm or less, Rotary axis ±2” or less.
  • The MX-150 combines 5-axis milling, turn milling, and grinding functions in a single unit.

Specifications

 MX-150

Workpiece size

Largest workpiece (mm) *

φ150×200

Maximum mass (kg)

10

Control axis

Travel

X/Y/Z(mm)

350/300/400

A/B(°)

360/-100~10

Maximum feed rate

X/Y/Z(mm)

40000

A/B(min-1)

1000/55

Minimum setting unit (mm/°)

0.0001

Tool spindle

Maximum spindle speed (min-1)

42000

Maximum output (kW)

15

Torque (Nm)

6

Tool interface

HSK-E40

ATC

Number of tools stored

20(Optional: 60)

Maximum tool length (mm)

150

Maximum tool diameter (mm)

φ50

Others

NC unit

FANUC 31iB

Required power supply

AC200/220V ±10%-15%
3-phase 50/60Hz ±1Hz

Power requirement (kVA)

51

Machine dimensions (W x L x H) (mm)

2200 x 2900 x 2060

Mass of machine (kg)

5000



Source: TECOTEC HCM
